Single Socket V1 (LGA-1851) supported, CPU TDP supports Up to 125W TDP
Core
Up to 24 cores
System Memory
Memory Capacity
4 DIMM slots
Up to 192GB Unbuffered ECC/non-ECC UDIMM, DDR5-5600MT/s
Supports up to 192GB of DDR5 UDIMM/CUDIMM with speeds of up to 4400MT/s with one DIMM, or 4000MT/s with two DIMM single rank, or 3600MT/s with two DIMM dual rank in four memory slots
Memory Type
5600 MT/s Up to 192GB of memory with speeds of up to 5600 MT/s(2DPC)
DIMM Sizes
8GB, 16GB, 24GB, 32GB, 48GB
Memory Voltage
1.1V
Error Detection
Corrects single-bit errors
Detects double-bit errors (using ECC memory)
On-Board Devices
Chipset
Intel W880
Audio
ALC 888S HD Audio
Network Controllers
Dual LAN with Intel® X550 10GBase-T Ethernet Controller
Dual LAN with Intel® I226LM Ethernet Controller
Input / Output
SATA
4 SATA3 (6Gbps) port(s)
USB
6 USB 3.2 Gen2 port(s) (4 rear type A; 2 via header)
